Full-Automatic Custom 500-20000l/H UHT Sterilizer For Different Types Of Liquid Products Milk/Juice/Sauce SUS304/316
Download to learn more
tubular sterilizer production introduce.pdf
Click to learn more
https://www.youtube.com/watch?v=6MGcJ049e6o&list=PLMqO7-CTBpXtUf9nzvIHNa66uz3jZ9MOI&index=6
UHT Sterilizer Overview:
The fully automated custom (Ultra High Temperature)UHT Sterilizer is a cutting-edge solution designed for efficient, reliable sterilization of a wide range of liquid products. UHT Sterilizer With a processing capacity of 500 to 20,000 liters per hour, this high-performance system is ideally suited for large-scale production environments.
UHT Sterilizer Main features:
Advanced sterilization technology: Using UHT sterilization technology, the liquid is quickly heated to a high temperature (usually 135-150°C) in a very short period of time, and then quickly cooled to ensure complete inactivation of microorganisms.
Customizable Design: Tailor-made to meet the specific requirements of different liquid products including milk, juices and sauces. Adapt to various production scales and processing needs.
Fully automatic:UHT Sterilizer Equipped with advanced control system to realize automation of the entire sterilization process. This includes temperature control, pressure monitoring and timing to ensure consistent quality and minimize human intervention.
HIGH QUALITY MATERIAL: Made of SUS304 and SUS316 stainless steel, known for its excellent corrosion resistance and durability. These materials ensure long-term performance and meet food safety standards.
Efficient heat exchange:UHT Sterilizer Use advanced heat exchange technology to optimize thermal efficiency and reduce energy consumption. The design minimizes heat loss and ensures efficient heat treatment.
User-friendly interface: Equipped with an intuitive touch screen control panel for easy operation and monitoring. Provides real-time data and alerts to help maintain optimal operating conditions.
Hygienic Design: UHT Sterilizer Design focused on hygiene and ease of cleaning. Features such as a CIP (Clean in Place) system are included to ensure the entire system is cleaned thoroughly and efficiently.
Versatility:UHT Sterilizer Suitable for a variety of liquid products, adaptable to different viscosities and formulations. Ideal for use in the dairy, beverage and food processing industries.
UHT Sterilizer application
| Typical application |
Mango pulp |
Coconut water |
UHT milk |
Fruit juice |
| Flow |
1000l/h |
3000l/h |
5000l/h |
8000l/h |
| Power |
13 |
11 |
12 |
20 |
| Temperature in |
40 |
4 |
4 |
55 |
| Sterilizing temperature |
108 |
80/ 140 |
137 |
125 |
| Holding time |
120 |
90 /8 |
5 |
15 |
| Temperature out |
40 |
10/35 |
25 |
85 |
| Note |
The flow and temperature could tailor-made as per project demand from 500-20,000L/h |
UHT Sterilizer Benefits:
Enhanced Product Safety: Ensures effective microbial elimination, extending shelf life and maintaining product safety.
Operational Efficiency: Streamlines the sterilization process with minimal manual intervention, reducing labor costs and human error.
Energy Savings: Optimizes energy usage through advanced heat exchange technology.
UHT Sterilizer Applications:
Dairy Industry: For sterilizing milk and cream.
Beverage Industry: Suitable for fruit juices, flavored drinks, and other liquid beverages.
Food Processing: Ideal for sauces, soups, and other liquid food products.
