Steam Heating Tunnel Beverage Pasteurizer Machine Auotmatic For Glass Bottle / Cans / Jars
Auotmatic steam heating tunnel beverage pasteurizer for glass bottle/cans/jars
Download to learn more
plate sterilizer production introduce.pdf
Click to learn more
https://youtu.be/iWMaI5oVbeA
The steam heated tunnel beverage pasteurizer is designed to pasteurize beverages packaged in glass bottles, jars or jars. This equipment uses steam to heat the product to a specific temperature and maintain it for a certain period of time, effectively killing harmful microorganisms and ensuring the safety and quality of the beverage. The machine's automated nature ensures high efficiency and consistent results. Here is a detailed overview of the steam heating tunnel beverage pasteurizer:
Pasteurizer main feature
Sturdy and hygienic construction:
Material: Made of high-quality stainless steel (SUS304/SUS316), durable and corrosion-resistant.
Hygienic design: Smooth surfaces and hygienic fittings prevent contamination and ensure easy cleaning.
Efficient heating system:
Steam Heating: Utilizes steam to provide consistent, efficient heating of products within the tunnel.
Temperature Control: Precise temperature control to maintain the desired pasteurization temperature throughout the process.
Automated operations:
PLC control system: Advanced automation technology can accurately control temperature, time and conveying speed to ensure the consistency of pasteurization.
User-friendly interface: touch screen control and display panel for easy operation and monitoring.
energy efficiency:
Heat recovery: Recovering heat from pasteurized products to preheat incoming products, thereby reducing energy consumption.
Insulation: Insulated tunnels minimize heat loss and increase energy efficiency.
Packaging compatibility:
Glass Bottles: For premium beverages that require a strong gas and moisture barrier.
Canning: Ideal for carbonated and non-carbonated beverages, providing a lightweight and durable packaging solution.
Jar: Suitable for various liquid and semi-liquid foods that require pasteurization.
Hygiene and cleanability:
CIP (Clean in Place) System: Automatic cleaning process ensures thorough cleaning without disassembly.
Hygienic design: Designed to prevent microbial contamination and ensure easy maintenance.
| Pasteurizing time( min) |
10--30 |
Pasteurizing temperature |
65-98℃,adjustable |
| Width of conveyor (mm) |
1000/1200/1500 |
Running speed |
frequency control |
| Voltage |
380v/50HZ (or customized) |
Power |
Conveyor motor: 3kw |
| Circulating water pump: 4kw |
| Steam pressure |
2kg, 0.3MPa |
Capacity(bottles/h) |
1500-2500 |
| Dimension(mm) |
10000*1500*1750 or 12000*2200*1750 (according to your capacity and pasteurizing time) |
Pasteurizer Process overview
loading:
Glass bottles, jars or jars are loaded onto a conveyor belt and transported into a steam-heated tunnel.
Warm up:
Heat recovered from the pasteurization process is used to preheat the product, optimizing energy efficiency.
Steam heating:
Steam is used to heat the product to pasteurization temperatures, maintaining the desired temperature for a specific period of time to kill harmful microorganisms.
Keep:
Store the product at pasteurization temperatures for the required time to ensure effective reduction of microorganisms.
cool down:
Pasteurized products are rapidly cooled to safe storage temperatures, preventing spoilage and maintaining quality.
freed:
Pasteurized and cooled product is unloaded from the conveyor belt for packaging and distribution.
Pasteurizer Application areas
Beverage Processing: Suitable for a variety of beverages including juices, sodas, teas and alcoholic beverages.
Food Processing: Ideal for liquid and semi-liquid foods such as sauces, soups and preserves.
Pasteurizer Customization options
Capacities: A variety of capacities are available to meet specific production volumes from small-scale production to large industrial production lines.
Temperature and Pressure: Adjustable settings to suit different types of products and processing conditions.
Material: SUS304 and SUS316 stainless steel are selected according to the acidity and chemical properties of the product.
Integration: compatible with existing processing lines and auxiliary equipment, running seamlessly.
Pasteurizer Maintenance and support
Routine Maintenance: Regular inspection and maintenance schedule to ensure optimal performance and longevity.
Training: A comprehensive training program is provided for operators and maintenance personnel to ensure proper use and maintenance.
Technical Support: Get technical support and spare parts to minimize downtime and ensure continuous operations.
Pasteurizer Benefit
Product safety: Ensure microbial safety and extend the shelf life of beverages.
Shelf life: Maintaining the nutritional value and sensory qualities of the product.
Efficiency: Optimized heat exchange and energy recovery systems reduce energy costs and increase processing efficiency.
Compliance: Meets strict regulatory standards for food safety and quality.
Investing in a steam heated tunnel beverage pasteurizer ensures efficient, safe and high-quality processing of beverages in glass bottles, jars or jars.
